Senor PicoPAD8
Rugged POS/Industrial Tablet PC


The Senor PicoPAD8 Tablet PC is a lightweight tablet PC that has been purposefully designed, developed and built for mobile Point Of Service (POS) applications such as Point of Sale, field service and sales.

Its sleek design and features makes the PicoPAD8 suitable for any size or type of businesses.

Providing businesses the flexibility to complete transactions directly with customers, the PicoPAD delivers convenience and versatility, giving a positive effect to customer satisfaction, customer loyalty and helps boost sales as an efficient system in place.

The PicoPAD8 offers a blend of performance, integrated features and mobility. Every Senor PicoPAD8 Tablet PC comes out of the box ready to work. Weighing only 400g the PicoPAD8 helps every user to work faster, smarter and more effectively, providing the capabilities, applications, and ergonomic ease-of-use that mobile workers need to be more productive in today’s de-centralized work environments.

Features

  • Bezel-less design
  • Space Saving
  • Optimised Charging & Docking Solutions (with lots of I/O ports)
  • Windows 10 IoT
  • Intel Intel Atom x5-Z8350 Processor
  • 3 Track MSR and NFC (Mifare) Readers
  • 12 Month warranty
Specifications
Physical Characteristics
Width 229 mm
Height 123 mm
Depth 12 mm
Weight 400g
Environmental Characteristics
Operating Temperature 0 to 40°C
Storage Temperature -20 to 60°C
Operating Humidity 20 to 90% (Non-Condensing)
Storage Humidity 20 to 93% (Non-Condensing)
System Specifications
Processor Intel Atom x5-Z8350, 1.44 GHz Turbo Boost up to 1.92 GHz
System Memory 2GB RAM (Factory fitted)
Video Out Connector Micro HDMI 1.4a
Storage 32GB eMMC
1 x micro SD card slot (max. 64 GB)
Audio 1 x Mic in / Line out
Display Specifications
Size 8"
Resolution 1280 x 800 pixels
Electrical Specifications
Battery Lithium Ion
External Power 5V, 0.3A
Wireless Specifications
Standard WiFi: 802.11a/g/n
Bluetooth: Bluetooth 4.0
User Interface
Touch Screen Capacitive 5 Point-Touch
Additional Interfaces
Standard USB Port
Docking Connector
Video Out(VGA)
|MicroSD Card Slot
Audio
Camera 5.0 Megapixel Rear Camera, 1.2 Megapixel Camera
Software
Operating System Windows IoT(32/64-bit)
Dock (included with Tablet)
Dock Ports Power, 1x Serial, Ethernet, 3x USB 2.0
Ordering Information and Pricing
Part Number Model Number Description RRP
Inc GST
T
%
[A] Senor PicoPAD8 Windows 10 IoT Tablet
PICOPAD8-XT PicoPAD 8 TFT LED, 1280x800, Intel Quad Core Atom X5-Z8350 1.55GHz Turbo Boost upto 1.92GHz, 2GB RAM, 32GB eMCC, Window 10 Enterprise IoT Entry and Docking Station $880.00 A
PICOPAD8-XP PicoPAD 8 TFT LED, 1280x800, Intel Quad Core Atom X5-Z8350 1.55GHz Turbo Boost upto 1.92GHz, 2GB RAM, 32GB eMCC, Window 10 Proe OEM and Docking Station $1,122.00 A
[B] Accessories
USB Cables
2-6260-020-8 CA6260-2 USB A to A Cable - 2m $4.40 U1
2-6260-030-4 CA6260-3 USB A to A Cable - 3m $8.80 U1
Ethernet Cables
2-6073-020-1 CA6073-2 Modular Patch RJ45 - 2m (Blue) $4.40 A
2-6073-030-3 CA6073-3 Modular Patch RJ45 - 3 (Blue) $4.40 A
2-6073-050-1 CA6073-5 Modular Patch RJ45 - 5m (Blue) $5.50 A
