Alien Technology - ALN 9841 Doc
UHF RFID Inlay

	Designed for stacked & dense packed documents, folders & other paper goods, the Higgs™-EC UHF RFID IC based “Doc” antenna design, offers superior performance and reliability for tagging of papers, files, documents, folders or other thin and tightly compact wood/organic materials. Potential applications include Legal, Academic and Medial, for use on Documents, Certificates, Folders, Envelopes, etc. Enhanced memory footprint includes a 48-bit Unique TID for authentication and serialization applications and password protected read and write support to prevent unauthorized viewing and modification of the tag’s data. ALN-9841 inlays are World Tag compliant, enabling consistent operation across the diverse frequencies of the Americas, Europe, Middle East, Asia, and Africa. Features Worldwide operation in all RFID UHF bands(840-960 MHz) Global GS1 Class 2 Gen 2 (V1.2.0) and ISO/IEC 18000-6C compliance 512-Bits of NVRAM Memory Up to 128 EPC bits (96-bits nominal) 128 User Bits 48 Bit Unique TID 32 Bit Access and 32 bit Kill Passwords User Memory can be Block Perma-Locked as well as read password protected in 32 Bit Blocks Class leading read and write performance BlastWrite™ and QuickWrite™ mass-encoding Dynamic Authentication™ - anti-cloning/anticounterfeit technology Available in high-yield, high capacity dry/wet inlay rolls

Designed for stacked & dense packed documents, folders & other paper goods, the Higgs™-EC UHF RFID IC based “Doc” antenna design, offers superior performance and reliability for tagging of papers, files, documents, folders or other thin and tightly compact wood/organic materials. Potential applications include Legal, Academic and Medial, for use on Documents, Certificates, Folders, Envelopes, etc.

Enhanced memory footprint includes a 48-bit Unique TID for authentication and serialization applications and password protected read and write support to prevent unauthorized viewing and modification of the tag’s data.

ALN-9841 inlays are World Tag compliant, enabling consistent operation across the diverse frequencies of the Americas, Europe, Middle East, Asia, and Africa.

Features

Worldwide operation in all RFID UHF bands(840-960 MHz)
Global GS1 Class 2 Gen 2 (V1.2.0) and ISO/IEC 18000-6C compliance
512-Bits of NVRAM Memory
Up to 128 EPC bits (96-bits nominal)
128 User Bits
48 Bit Unique TID
32 Bit Access and 32 bit Kill Passwords
User Memory can be Block Perma-Locked as well as read password protected in 32 Bit Blocks
Class leading read and write performance
BlastWrite™ and QuickWrite™ mass-encoding
Dynamic Authentication™ - anti-cloning/anticounterfeit technology
Available in high-yield, high capacity dry/wet inlay rolls

Specifications

Physical Characteristics
Dimensions (Wet Inlay)	108 mm x 16 mm
Adhesive	General Purpose Permanent
Overlay	TT Printable White Film
Environmental Characteristics
Shelf Life	2 Years @ 25°C 40% Relative Humidity (Non-Condensing)
Shelf Storage Limits	-25°C to +50°C 20% to 90% Relative Humidity (Non-Condensing)
Application Temperature	Greater Than -4°C
Operating Limits	-40°C to +70°C 20% to 90% Relative Humidity (Non-Condensing)
ESD Limit	HBM: 5.0kV CDM: 1.5kV
RFID Characteristics
RF Protocol	EPCglobal Class 1, Gen 2(ISO 18000-6C)
Operating Frequency Range	840 to 960 MHz
Operating Mode	Passive
Tag Characteristics
Memory	EPC: Up to 128 bits (96-bits nominal) User: 128 bits TID: 32 bits TID: 48 bits
IC	Alien Higgs-EC
Read Range	TBA

**Ordering Information and Pricing**
Part Number	Model Number	Description	RRP Inc GST	T %
[A] Sample Tags
ALN-9841-WRW-1	ALN-9841	Alien Doc, White Wet Inlay, Higgs-EC, Each	$0.44	A
[B] Rolls
ALN-9841-WRW	ALN-9841	Alien Doc, White Wet Inlay, Higgs-EC, 20K	$4,961.00	A
