Custom Cables - General Assemblies


UMD offers Manufacturing and Assembly Services for general custom cable assemblies.

Ordering Information and Pricing
Part Number Model Number Description RRP
Inc GST		 T
%
[A] Step 1 - Cable Type type and Length
Screened Cable
2-1010-004-0 Cable, Screened, 4 core $1.32 C
2-1010-006-6 Cable, Screened, 6 core $1.76 C
2-1010-008-2 Cable, Screened, 8 core $2.20 C
2-1010-012-1 Cable, Screened, 12 core $2.75 C
Un-Screened Cable (Telephone)
2-2010-004-2 Cable, Telephone Flat, 4 core $0.55 U3
2-2010-006-8 Cable, Telephone Flat, 6 core $1.10 U3
2-2010-008-4 Cable, Telephone Flat, 8 core $1.98 U3
Data Network Cable
2-2020-031-3 Cable UTP Cat 5 4 Pair twisted (Per meter) $4.18 U3
Fig 8
2-1012-010-9 Cable fig 8 Red/Black - High Current $5.61 U3
2-1012-011-6 Cable fig 8 Red/Black - Standard $5.61 U3
2-1012-020-8 Cable fig 8, 24/0.2. Black (p/m) $1.43 U3
[B] Step 2 - Select Connectors. One for each end.
D Connectors (also include backshell)
1-0000-009-3 Conn, D9P Plug, Solder $0.99 A
1-0000-015-8 Conn, D15P Solder $0.77 A
1-0000-025-5 Conn, D25P Solder $0.88 A
1-0001-009-8 Conn, D9S Solder $0.55 A
1-0001-015-3 Conn, D15S Solder $0.77 A
1-0001-025-0 Conn, D25S Solder $0.77 A
1-0002-009-3 Conn, D9 B/Shell Plastic Grey $0.77 A
1-0002-015-8 Conn, D15 B/Shell Plastic Grey $0.88 A
1-0002-025-5 Conn, D25 B/Shell Plastic Grey $0.88 A
DIN (Audio) Connector
1-0010-005-5 Conn, DIN Line Plug, 5 Pin 180deg $2.75 A
1-0010-006-3 Conn, DIN Line Plug, 6 Pin $2.75 A
1-0010-008-9 Conn, DIN Line Plug, 8 Pin $4.07 A
M12 Series (Industrial)
1-0022-004-6 CON-M12-L-P-4 Conn, M12 In-Line Plug 4 way $11.11 A
1-0022-005-6 CON-M12-L-P-5 Conn, M12 In-Line Plug 5 way $11.66 A
1-0022-008-1 CON-M12-L-P-8 Conn, M12 In-Line Plug 8 way $71.17 A
1-0022-014-8 CON-M12-P-P-4 Conn, M12 Panel Mount Plug 4 way $15.73 A
1-0022-015-5 CON-M12-P-P-5 Conn, M12 Panel Mount Plug 5 way $16.61 A
1-0022-104-3 CON-M12-L-S-4 Conn, M12 In-Line Socket 4 way $14.63 A
1-0022-105-6 CON-M12-L-S-5 Conn, M12 In-Line Socket 5 way $15.84 A
1-0022-108-9 CON-M12-L-S-8 Conn, M12 In-Line Socket 8 way $38.94 A
1-0022-114-5 CON-M12-P-S-4 Conn, M12 Panel Mount Socket 4 way $15.62 A
1-0022-115-2 CON-M12-P-S-5 Conn, M12 Panel Mount Socket 5 way $13.20 A
Microphone
1-0040-003-8 Conn, MIC Line Plug, 3 pin $2.75 A
1-0041-003-7 Conn, MIC Line Socket, 3 pin $2.97 A
1-0041-005-1 Conn, MIC Line Socket, 5 pin $3.41 A
1-0041-008-2 Conn, MIC Line Socket, 8 pin $3.52 A
DC Power
1-0051-013-3 Conn, DC Power Line Plug 1.3mm $2.75 A
1-0051-020-0 Conn, DC Power Line Plug 2.0/2.1mm, 9.5mm Shaft $2.09 A
1-0051-025-1 Conn, DC Power Line Plug 2.5mm $2.86 A
1-0051-121-5 Conn, DC Power Line Plug, with Locking Screw, 2.1mm $5.28 A
1-0051-125-3 Conn, DC Power Line Plug, with Locking Screw, 2.5mm $5.28 A
Modular RJ Series
1-0160-010-9 M10P10C Conn, Modular RJ71 Plug, 10x10 $7.15 A
1-0160-044-8 M4P4C Conn, Modular RJ11 Plug, 4x4 $0.44 A
1-0160-046-4 M6P4C Conn, Modular RJ12 Plug, 4x6 $0.44 A
1-0160-066-8 M6P6C Conn, Modular RJ12 Plug, 6x6 $0.88 A
1-0160-088-9 M8P8C Conn, Modular RJ45 Plug, 8x8 $0.44 A
C16 Series - IP67 Waterproof
1-0167-104-8 C16-1 Conn, Amp Line Socket Circular, 3+1 (4w) $25.30 A
1-0168-004-0 Conn, Amp Line Plug Circular, 4 Pin $19.36 A
1-0168-007-1 Conn, Amp Line Plug Circular, 7 Pin $24.20 A
Hirose
1-0290-008-7 Conn, Hirose QM30-8P-EP IDC Pl $10.34 A
1-0291-016-0 Conn, Hirose 3540-16P-CV $35.75 A
1-0299-008-2 Conn, Hirose QM-8-CV Hood Case $9.02 A
JAE
1-0300-014-3 Conn, JAE Tx20A-14PH1-D2P1-D1 $31.02 A
[C] Step 3 - Selection Production Assembly Service
8-9030-201-4 Production Service Custom General Cable Assembly $77.00 P
[D] Step 4 - Advise UMD Sales. Please include wiring diagram.
Simply send order in writing to sales@umd.com.au. Please include UMD Part Numbers and Quantities.
