UMD Model 529A
UMD VAST™ Standard Validator

	The UMD Model 529 (M529) Standard Validator is part of the UMD VAST™ lineup of Validators used for scanning tickets or NFC tags to enable patron entry to venues or attractions. The Validator is cloud-connected to the UMD VAST™ access control and ticketing system and optionally controls ingress and egress via a connected turnstile, gate or other physical barriers. The M529 Validator can be integrated with almost any barrier system and uses solid-state relay outputs for activation of the barrier.† The Validator allows patrons to scan their ticket barcode or tap their NFC passes to gain entry to the venue or to record their presence at the venue via the UMD VAST™ cloud service. A key feature of the M529 Validator is the inclusion of a 7” high-brightness LCD for displaying instructions and responses to the patrons as well as streaming video for patron information or advertising. Mounting of the M529 is to a wall adjacent to the venue entry and requires power and a wired LAN connection to operate. This design allows easy access for installation and maintenance. Features Linux based microcontroller for fast and flexible applications Standard UMD VAST™ Validator software pre-installed LAN connected for reliable communications with the host ticketing service Remote monitored/managed via the UMD VAST™ web console interface Rugged 316 Grade Stainless Steel enclosure ensures longevity and serviceability in exposed environments‡ Fast and aggressive presentation style barcode scanner for reading 1D or 2D barcodes on paper or mobile devices NFC Mifare 1k compatible tag reader for contactless membership cards or NFC wristbands Multifunction, multicolour LED indicator to show successful scan, rejected scan, system error or other programmed conditions such as concession tickets using different colours 7" LCD Patron display for instruction, responses, and video streaming Online business hours support is included where you purchase an ongoing UMD VAST™ device access licence subscription 12 Months Warranty

The UMD Model 529 (M529) Standard Validator is part of the UMD VAST™ lineup of Validators used for scanning tickets or NFC tags to enable patron entry to venues or attractions.

The Validator is cloud-connected to the UMD VAST™ access control and ticketing system and optionally controls ingress and egress via a connected turnstile, gate or other physical barriers.

The M529 Validator can be integrated with almost any barrier system and uses solid-state relay outputs for activation of the barrier.†

The Validator allows patrons to scan their ticket barcode or tap their NFC passes to gain entry to the venue or to record their presence at the venue via the UMD VAST™ cloud service.

A key feature of the M529 Validator is the inclusion of a 7” high-brightness LCD for displaying instructions and responses to the patrons as well as streaming video for patron information or advertising.

Mounting of the M529 is to a wall adjacent to the venue entry and requires power and a wired LAN connection to operate. This design allows easy access for installation and maintenance.

Features

Linux based microcontroller for fast and flexible applications
Standard UMD VAST™ Validator software pre-installed
LAN connected for reliable communications with the host ticketing service
Remote monitored/managed via the UMD VAST™ web console interface
Rugged 316 Grade Stainless Steel enclosure ensures longevity and serviceability in exposed environments‡
Fast and aggressive presentation style barcode scanner for reading 1D or 2D barcodes on paper or mobile devices
NFC Mifare 1k compatible tag reader for contactless membership cards or NFC wristbands
Multifunction, multicolour LED indicator to show successful scan, rejected scan, system error or other programmed conditions such as concession tickets using different colours
7" LCD Patron display for instruction, responses, and video streaming
Online business hours support is included where you purchase an ongoing UMD VAST™ device access licence subscription
12 Months Warranty

Specifications

Mechanical
Overall Dimensions	223 W x 309 H x 132 D (mm) Including LED Indicator Dome
Housing Only	223 W x 271 H x 132 D (mm)
Wall/VESA Mount Plate	223 W x 271 H (mm) VESA 100 mm mounting holes
Material	316 Grade 0.9 mm Stainless Steel
Finish	Brushed Natural Finish ("Linish")
Environmental	IP54 (Estimated)
Ambient Operating Temperature	0°C - 40°C
Controller
Processor	Linux Computer (UMD M800 Series)
Communications	Wired Ethernet
I/O	4 x USB 1 x RS232 for NFC Reader 5 x Solid State Relay Outputs (60V/0.2A, 3 for LED Accunciator, 1 for Turnstile release, 1 for freewheel output) 2 x Opto-isolated Inputs (1 for rotate input, 1 for lane busy input)
Power Supply Requirement	9 to 36VDC / 4 A or PoE (802.3af)
User Interface
Display	7” TFT LCD with video streaming playback capability
Annunciator	RGB LED dome
Audio	Buzzer
Access	Cam Lock
	†RS232 and Weigand are under development
	‡Not suitable for full outdoor installation

**Ordering Information and Pricing**
Part Number	Model Number	Description	RRP Inc GST	T %
[A] UMD Model 529A Validator
M529A11E01V1	M529A-EDE	UMD Standard Series Turnstile Head, 1 Way (LCD), RGB Dome Anunciator, Enclosure, Ethernet, with VAST NG Validator Software
